430J1L

*Type Austenite

Characteristics

    Cu and Nb are added to 430 stainless steel. It has superior corrosion resistance, drawability, weldability and high temperature oxidation resistance.

Chemical compositions and physical properties

Designations Chemical compositions (%) Mechanical properties Physical properties
 JIS   POSCO   C   Cr   Ni   Mo   Orthers   Yield
 Strength
 N/mm²
 Tensile
 Strength
 N/mm²
 Elongate

 %
 Hadness

 Hv
 Specific
 Heat
 J/gºC
 Specific
 Gravity
 Thermal
 Expansion
 Coefficient
 W/m-ºC
 Thermal
 Conductivity
 W/m-ºC
 430J1L   430J1L   ≤0.025   11.6~20.0   -   -   N≤0.025   ≥205   ≥390   ≥22   ≤200   0.46   7.7   10.4   26.2

Applications

    - Production: kitchen utensils, household appliances, water tanks.
    - Refractory equipment: parts of a car exhaust pipe.
    - Exterior material: die-cast shell, exterior construction material, Guardail tube.
